מסך LED פנים DS-D40S-2F

מפרט טכני

Product Model

DS-D4012CS-1F

Product Type

LED Display Structure

Pixel Configuration

SMD Triad LED

Modules Component

2 × 3

Dimensions (W × H × D)

640 (W) mm × 480 (H) mm ×36 (D) mm (25.197'' × 1.898'' × 1.42'')

Area

0.3072 ㎡

Cabinet Material

Die cast aluminum

Maintenance Method

Complete front maintenance

Dimension (W × H × D)

320 mm × 160 mm

Module Resolution

256 × 128

White Balance Brightness

600 cd/㎡

Color Temperature

3000-10000 K adjustable

Viewing Angle

160°(H)/160°(V)

Contrast Ratio

5000:1

Color Uniformity

≤ ± 0.003Cx，Cy

Brightness Uniformity

≥ 97％

Driving Method

Constant current driving

Frame Frequency

60 Hz

Refresh Rate

3840 Hz

Grey Level

Up to 16 bit

Max. Consumption

450W/㎡

Average Consumption

150W/㎡

Input Voltage

100~240 VAC ± 10％

Working Temperature

-10 ℃ to 40 ℃ (14 ℉ to 104 ℉)

Working Humidity

10% to 60% RH (without condensation)

Storage Temperature

-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)

Storage Humidity

10% to 85% RH (without condensation)

Package Dimension (W × H × D)

760 (W) mm × 318 (H) mm × 587 (D) mm (29.92 '' × 12.52 '' × 23.11 '')

Packing List

Regulatory Compliance and Safety Information × 1 Several Joint pieces,Fixing screws and Signal cables Several LED lamp beads and IC components

Gross Weight

4.7 kg (10.3 lb.)

Net Weight

3.7 kg (8.15 lb.)

Modular Bracket

DS-DL116448W 1*1;DS-DL126448W 1*2;DS-DL226448W 2*2
