מסך LED להשכרה DS-D4629CE-1AS/M

מפרט טכני

Product Type

Spare Modules Package

Pixel Configuration

SMD Triad LED

Pixel Pitch Category

P2.9

Pixel Pitch

2.9762 mm

Resolution

84x84

Pixel Density

112896 dots/m²

Lamp Board Housing

With housing

Maintenance Method

Rear maintenance

White Balance Brightness

1000 cd/㎡

Color Temperature

6500K adjustable

Viewing Angle

Horizontal 160°, vertical 140°

Contrast Ratio

≥ 6000:1

Color Uniformity

≤ ± 0.004Cx，Cy

Brightness Uniformity

≥ 97％

Frame Frequency

50/60 Hz

Refresh Rate

7680 Hz

Grey Level

14 bit

Lamp Encapsulation

SMD2020

Control System

Hikvision

Working Temperature

-20 ℃ to +45 ℃ (-4℉ to +113℉)

Working Humidity

10%~90%RH (No condensation)

Storage Humidity

10%~90%RH (No condensation)

Storage Temperature

-40 ℃ to +60 ℃ (-40℉ to +140 ℉)
