בקר LED DS-DT60P-02HI04NO-B

מפרט טכני

Brightness Control

1 to 100 tunable (level-by-level white balance)

Input Frame Rate

25 Hz to 60 Hz

Grey Level

256

Display Color

16 MP

Processing Depth

8 bit

Image Scaling

Supported

Product Model

DS-DT60P-02HI04NO-B

Chassis Height

1 U

Chassis Width

Half-width

Light Sensor Port

Not supported

Average Consumption

≤16.5 W

Power Interface Quantity

1

Power Interface

100 to 240 VAC, 50/60 Hz

USB Interface

1 channel of USB 2.0 + 1 channel of USB 3.0

Serial Interface

1 × debugging serial port (4-pin connector) + 1 × RS-485 central control serial port (green Phoenix contact) Baud rate: 115200, data bit: 8

Control Network Port

2 × 10/100/1000 Mbps auto-sensing Ethernet port (RJ-45),Connects to the external network.

Open Windows

3 signal source windows + 2 image windows + 1 scrolling text window + 1 background window

Layers per Device

7

Scenes

10

Background Images

1

Background Resolution

Min.: 640 × 480, Max.: 1920 × 1200

Background Format

JPG/JPEG

Subtitles

1

Subtitle Width

32760

Subtitle Font

Supports Xiaomi font and custom font

Screen

128 × 64, OLED screen

Working Temperature

-10°C to 50°C

Storage Humidity

10% to 90%

Working Humidity

10% to 90%

Storage Temperature

-10°C to 50°C

Packaging Size (W × H × D)

353 mm × 89 mm × 237 mm (13.90 inch × 3.50 inch × 9.33 inch)

Net Weight

1.03 kg (2.271 lb)

Gross Weight

1.60 kg (3.527 lb)

Dimensions (W × H × D)

210 mm × 42 mm × 180 mm (8.26 inch × 1.65 inch × 7.08 inch)

Packing List

1 × AC power cord, 1 × connecting bracket, 1 × mounting bracket, 1 × RS-485 green Phoenix contact for central control device, 1 × regulatory compliance and safety information manual, 1 × bar antenna, 1× RF remote control

Product Type

LED controller

Audio Input Interfaces

3

Audio Input Interface Type

2 HDMI1.4 + 1 channel of embedded Android

Video Input Interfaces

3

Video Input Interface Type

2 HDMI 1.4 + 1 embedded Android

Max. Video Input Resolution

1080P

Video Input Resolution

HDMI 1.4 port: Max. resolution: 1920 × 1200@60 Hz Min. resolution: 320 × 180@60 Hz Supports custom resolution. Total resolution should be no more than 2.6 MP@60 Hz Max. width: 144 to 4096, alignment: 2 alignment Max. height: 144 to 4096, alignment: 1 alignment Supports HDCP 1.4. Interlacing signal input is not supported.,Embedded Android: Max. resolution: 1920 × 1200@60 Hz Min. resolution: 320 × 180@60 Hz Supports custom resolution. Total resolution should be no more than 2.6 MP@60 Hz Max. width: 144 to 4096, alignment: 2 alignment Max. height: 144 to 4096, alignment: 1 alignment Supports HDCP 1.4. Interlacing signal input is not supported.

Video Input Processing Feature

Processing depth: 8 bit Sampling format: RGB: 444 YUV: 444 YUV: 422

Built-in Android Resolution

1080p

Max. Video Output Resolution

Mini loading mode: 2600000 Standard loading mode: 2925000

Video Live View Output Interfaces

1

Type of Video Live View Output Interface

HDMI 1.4

Loading Capacity for Video Output to LED

Mini loading mode: Single port load 650000, Width 144 - 5120, Alignment: multiple of 2, Height 64 - 5120, Alignment: multiple of 1, Max. load does not exceed 2600000; Standard loading mode: Single port load 2925000, Width 144 - 5120, Alignment: multiple of 2; Height 64 - 5120, Alignment: multiple of 1; Max. load does not exceed 2925000

Video Live View Output Resolution

720p@60 Hz

LED Loading Interfaces

4

LED Loading Interface Type

RJ-45

Loading Mode

Mini loading mode: Single port max load 650000 Standard loading mode: Single port max load 2925000 (only ports 1 and 2 available)

Audio Output Interfaces

1

Audio Output Interface

3.5 mm audio output

System

Android 12

Memory Capacity

2 GB

Storage Capacity

8 GB

CPU

4-core 64-bit ARM cortex-A55 2.0 GHz

Wi-Fi

2.4 GHz

Bluetooth

Bluetooth 4.0

Antenna

1 × bar antenna

Remote Control

Supports IR remote control

Button

+: increase brightness -: decrease brightness Source: change signal source

Power Switch

Button switch

WonderCast Client

Supported

Program Material Type

Video, image, webpage, document, clock, text, and background music

Video Playback Performance

1-channel 4096 × 2160@60 Hz, 4-channel 1920 × 1080@60 Hz, 6-channel 1280 × 720@60 Hz

Indicator

Active: The device is running. Source: The signal source is accessed. Error: The device operation exception occurs.

IR Input

1 × 3.5 mm connector Supports the access of IR remote control.
